Temperature & Humidity Chamber Specification / 항온항습조 ( 일반형 ) |
|||||||
|
ITH-MT Series |
ITH-MHT Series |
|||||
Temperature Range |
-40℃ ~ +100℃ |
-40℃ ~ +150℃ |
|||||
Humidity Range |
20%RH ~ 98%RH |
20%RH ~ 98%RH |
|||||
MODEL |
ITH-150-MT |
ITH-300-MT |
ITH-800-MT |
ITH-150-MHT |
ITH-300-MHT |
ITH-800-MHT |
|
Dimension ( W x D x H )mm |
Internal |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
External |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
|
Capacity |
150Liter |
336Liter |
800Liter |
150Liter |
336Liter |
800Liter |
|
Weight |
320Kg |
400Kg |
600Kg |
360Kg |
500Kg |
750Kg |
|
Temperature |
Fluctuation |
±0.3℃ ( -40℃ to +100℃ ), ±0.5℃ ( +100℃ to +150℃ ) |
|||||
Uniformity |
±1.0℃ ( -40℃ to +100℃ ), ±1.5℃ ( +100℃ to +150℃ ) |
||||||
Humidity |
Fluctuation |
±1.5%RH |
|||||
Uniformity |
±3.0%RH |
||||||
Time |
Heat-Up Rate |
+20℃ ~ +100℃ ( Within 50Min ) |
+20℃ ~ +150℃ ( Within 80Min ) |
||||
Pull-Down Rate |
+20℃ ~ -40℃ ( Within 60Min ) |
||||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( Polish ) |
|||||
External |
CR Steel Plate ( 아이보리 햄마톤 도장 ) |
||||||
Insulation |
Polyurethane Foam ( For Main Unit ) |
Glass Wool |
|||||
Refrigeration |
Refrigerator |
Hermatically sealed Compressor |
|||||
System |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
||||||
Capacity |
3/4HP x 2Unit |
1.5HP x 2Unit |
3HP x 2Unit |
3/4HP x 2Unit |
1.5HP x 2Unit |
3HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
3KW |
4KW |
6.6KW |
3.2KW |
4.5KW |
7.2KW |
|
Wet Heater |
Material |
SUS316L Sheathed Heater |
|||||
Capacity |
2KW |
3KW |
5KW |
2KW |
3KW |
5KW |
|
Air Circulation |
Motor |
90W |
90W x 2 |
90W x 4 |
90W |
90W x 2 |
90W x 4 |
Fan |
3" x 6" ( AL Sirocco ) |
||||||
Sensor |
Temperature |
PT 100Ω |
|||||
Humidity |
Electronic Sensor |
||||||
View Window |
250 x 400 x 41T |
300 x 450 x 41T |
500 x 650 x 41T |
250 x 400 x 41T |
300 x 450 x 41T |
500 x 650 x 41T |
|
Accessories |
Cable Port ( 내경 : Φ50, 1EA ), Shelves ( 2Set ), Halogen Lamp ( 50W ), Casters With Adjusters, Tower Lamp ( LED 3단 ) |
||||||
Power Supply |
AC220V 1Φ 3W 50/60Hz, AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz |
||||||
Max Power |
6.4KW |
9.6KW |
16.7KW |
6.6KW |
10.1KW |
17.3KW |
|
Load Current |
AC220V 1Φ |
29.1A |
43.6A |
- |
30A |
45.9A |
- |
AC220V 3Φ |
16.7A |
25.2A |
43.9A |
17.3A |
26.5A |
45.5A |
|
AC380V 3Φ |
Option |
Option |
25.4A |
Option |
Option |
26.3A |
|
Temperature & Humidity Chamber Special Specification / 항온항습조 ( 주문형 ) |
|||||||
|
ITH-T Series |
ITH-LHT Series |
|||||
Temperature Range |
-20℃ ~ +100℃ |
-70℃ ~ +150℃ |
|||||
Humidity Range |
20%RH ~ 98%RH |
20%RH ~ 98%RH |
|||||
MODEL |
ITH-150-T |
ITH-300-T |
ITH-800-T |
ITH-150-LHT |
ITH-300-LHT |
ITH-800-LHT |
|
Dimension ( W x D x H )mm |
Internal |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
External |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
1030 x 990 x 1700 |
1130 x 1190 x 1900 |
1550 x 1340 x 2170 |
|
Capacity |
150Liter |
336Liter |
800Liter |
150Liter |
336Liter |
800Liter |
|
Weight |
290Kg |
350Kg |
500Kg |
320Kg |
450Kg |
750Kg |
|
Temperature |
Fluctuation |
±0.3℃ ( -20℃ to +100℃ ) |
±0.3℃ ( -70℃ to +100℃ ), ±0.5℃ ( +100℃ to +150℃ ) |
||||
Uniformity |
±1.0℃ ( -20℃ to +100℃ ) |
±1.0℃ ( -70℃ to +100℃ ), ±1.5℃ ( +100℃ to +150℃ |
|||||
Humidity |
Fluctuation |
±1.5%RH |
|||||
Uniformity |
±3.0%RH |
||||||
Time |
Heat-Up Rate |
+20℃ ~ +100℃ ( Within 50Min ) |
+20℃ ~ +150℃ ( Within 80Min ) |
||||
Pull-Down Rate |
+20℃ ~ -20℃ ( Within 40Min ) |
+20℃ ~ -70℃ ( Within 90Min ) |
|||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( Polish ) |
|||||
External |
CR Steel Plate ( 아이보리 햄마톤 도장 ) |
||||||
Insulation |
Polyurethane Foam ( For Main Unit ) |
Glass Wool |
|||||
Refrigeration |
Refrigerator |
Hermatically sealed Compressor |
|||||
System |
Single Stage Refrigeration System |
Mechanical Cascade Refrigeration System |
|||||
Capacity |
3/4HP |
1.5HP |
3HP |
2HP x 2Unit |
3HP x 2Unit |
5HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
3KW |
4KW |
6.6KW |
4.5KW |
7.2KW |
12KW |
|
Wet Heater |
Material |
SUS316L Sheathed Heater |
|||||
Capacity |
2KW |
3KW |
5KW |
3KW |
5KW |
8KW |
|
Air Circulation |
Motor |
90W |
90W x 2 |
90W x 4 |
90W |
90W x 2 |
90W x 4 |
Fan |
3" x 6" ( AL Sirocco ) |
||||||
Sensor |
Temperature |
PT 100Ω |
|||||
Humidity | Electronic Sensor | ||||||
View Window | 250 x 400 x 41T | 300 x 450 x 41T | 500 x 650 x 41T | 250 x 400 x 41T | 300 x 450 x 41T | 500 x 650 x 41T | |
Accessories | Cable Port ( 내경 : Φ50, 1EA ), Shelves ( 2Set ), Halogen Lamp ( 50W ), Casters With Adjusters, Tower Lamp ( LED 3단 ) | ||||||
Power Supply | AC220V 1Φ 3W 50/60Hz, AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz | ||||||
Max Power | 5.8KW | 8.4KW | 14.1KW | 10.7KW | 16.9KW | 28KW | |
Load Current | AC220V 1Φ | 26.4A | 38.2A | - | 48.6A | - | - |
AC220V 3Φ | 15.2A | 22.1A | 37.1A | 28.1A | 44.4A | 73.6A | |
AC380V 3Φ |
Option |
Option |
21.5A |
16.3A |
25.7A |
42.6A |
|
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
Low Humidity Temperature Chamber Specification / 저습항온항습조 |
|||||||
|
ITH-MTL Series |
ITH-MHTL Series |
|||||
Temperature Range |
-40℃ ~ +100℃ |
-40℃ ~ +150℃ |
|||||
Humidity Range |
10%RH ~ 98%RH |
10%RH ~ 98%RH |
|||||
MODEL |
ITH-150-MTL |
ITH-300-MTL |
ITH-800-MTL |
ITH-150-MHTL |
ITH-300-MHTL |
ITH-800-MHTL |
|
Dimension ( W x D x H )mm |
Internal |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
External |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
|
Capacity |
150Liter |
336Liter |
800Liter |
150Liter |
336Liter |
800Liter |
|
Weight |
320Kg |
400Kg |
600Kg |
360Kg |
500Kg |
750Kg |
|
Temperature |
Fluctuation |
±0.3℃ ( -40℃ to +100℃ ), ±0.5℃ ( +100℃ to +150℃ ) |
|||||
Uniformity |
±1.0℃ ( -40℃ to +100℃ ), ±1.5℃ ( +100℃ to +150℃ ) |
||||||
Humidity |
Fluctuation |
±2.5%RH |
|||||
Uniformity |
±3.0%RH |
||||||
Time |
Heat-Up Rate |
+20℃ ~ +100℃ ( Within 50Min ) |
+20℃ ~ +150℃ ( Within 80Min ) |
||||
Pull-Down Rate |
+20℃ ~ -40℃ ( Within 60Min ) |
||||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( Polish ) |
|||||
External |
CR Steel Plate ( 아이보리 햄마톤 도장 ) |
||||||
Insulation |
Polyurethane Foam ( For Main Unit ) |
Glass Wool |
|||||
Refrigeration |
Refrigerator |
Hermatically sealed Compressor |
|||||
System |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
||||||
Capacity |
3/4HP x 2Unit |
1.5HP x 2Unit |
3HP x 2Unit |
3/4HP x 2Unit |
1.5HP x 2Unit |
3HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
3KW |
4KW |
6.6KW |
3.2KW |
4.5KW |
7.2KW |
|
Wet Heater |
Material |
SUS316L Sheathed Heater |
|||||
Capacity |
2KW |
3KW |
5KW |
2KW |
3KW |
5KW |
|
Air Circulation |
Motor |
90W |
90W x 2 |
90W x 4 |
90W |
90W x 2 |
90W x 4 |
Fan |
3" x 6" ( AL Sirocco ) |
||||||
Sensor |
Temperature |
PT 100Ω |
|||||
Humidity | Electronic Sensor | ||||||
View Window | 250 x 400 x 41T | 300 x 450 x 41T | 500 x 650 x 41T | 250 x 400 x 41T | 300 x 450 x 41T | 500 x 650 x 41T | |
Accessories | Cable Port ( 내경 : Φ50, 1EA ), Shelves ( 2Set ), Halogen Lamp ( 50W ), Casters With Adjusters, Tower Lamp ( LED 3단 ) | ||||||
Power Supply | AC220V 1Φ 3W 50/60Hz, AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz | ||||||
Max Power | 6.4KW | 9.6KW | 16.7KW | 6.6KW | 10.1KW | 17.3KW | |
Load Current | AC220V 1Φ | 29.1A | 43.6A | - | 30A | 45.9A | - |
AC220V 3Φ | 16.7A | 25.2A | 43.9A | 17.3A | 26.5A | 45.5A | |
AC380V 3Φ |
Option |
Option |
25.4A |
Option |
Option |
26.3A |
|
※ 제습기는 사양 협의 후 결정
Temperature Chamber Specification / 항온조 ( 일반형 ) |
|||||||
|
IT-MT Series |
IT-MHT Series |
|||||
Temperature Range |
-40℃ ~ +100℃ |
-40℃ ~ +150℃ |
|||||
MODEL |
IT-150-MT |
IT-300-MT |
IT-800-MT |
IT-150-MHT |
IT-300-MHT |
IT-800-MHT |
|
Dimension ( W x D x H )mm |
Internal |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
500 x 500 x 600 |
600 x 700 x 800 |
1000 x 800 x 1000 |
External |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
1030 x 930 x 1700 |
1130 x 1130 x 1900 |
1550 x 1280 x 2170 |
|
Capacity |
150Liter |
336Liter |
800Liter |
150Liter |
336Liter |
800Liter |
|
Weight |
320Kg |
400Kg |
600Kg |
360Kg |
500Kg |
750Kg |
|
Temperature |
Fluctuation |
±0.3℃ ( -40℃ to +100℃ ), ±0.5℃ ( +100℃ to +150℃ ) |
|||||
Uniformity |
±1.0℃ ( -40℃ to +100℃ ), ±1.5℃ ( +100℃ to +150℃ ) |
||||||
Time |
Heat-Up Rate |
+20℃ ~ +100℃ ( Within 50Min ) |
+20℃ ~ +150℃ ( Within 80Min ) |
||||
Pull-Down Rate |
+20℃ ~ -40℃ ( Within 60Min ) |
||||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( Polish ) |
|||||
External |
CR Steel Plate ( 아이보리 햄마톤 도장 ) |
||||||
Insulation |
Polyurethane Foam ( For Main Unit ) |
Glass Wool |
|||||
Refrigeration |
Refrigerator |
Hermatically sealed Compressor |
|||||
System |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
||||||
Capacity |
3/4HP x 2Unit |
1.5HP x 2Unit |
3HP x 2Unit |
3/4HP x 2Unit |
1.5HP x 2Unit |
3HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
3KW |
4KW |
6.6KW |
3.2KW |
4.5KW |
7.2KW |
|
Air Circulation |
Motor |
90W |
90W x 2 |
90W x 4 |
90W |
90W x 2 |
90W x 4 |
Fan |
3" x 6" ( AL Sirocco ) |
||||||
Temp. Sensor |
PT 100Ω |
||||||
View Window |
250 x 400 x 41T |
300 x 450 x 41T |
500 x 650 x 41T |
250 x 400 x 41T |
300 x 450 x 41T |
500 x 650 x 41T |
|
Accessories |
Cable Port ( 내경 : Φ50, 1EA ), Shelves ( 2Set ), Halogen Lamp ( 50W ), Casters With Adjusters, Tower Lamp ( LED 3단 ) |
||||||
Power Supply | AC220V 1Φ 3W 50/60Hz, AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz |
||||||
Max Power |
6.4KW |
9.6KW |
16.7KW |
6.6KW |
10.1KW |
17.3KW |
|
Load Current |
AC220V 1Φ |
29.1A |
43.6A |
- |
30A |
45.9A |
- |
AC220V 3Φ | 16.7A | 25.2A | 43.9A | 17.3A | 26.5A | 45.5A | |
AC380V 3Φ |
Option |
Option |
25.4A |
Option |
Option |
26.3A |
|
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
