Temperature & Humidity Room Chamber Specification / 항온항습실 ( 일반형 ) | |||||||
| ITH-RT Series | ITH-RMT Series | |||||
Temperature Range | -20℃ ~ +80℃ | -40℃ ~ +80℃ | |||||
Humidity Range | 20%RH ~ 98%RH | 20%RH ~ 98%RH | |||||
MODEL | ITH-R8000-T | ITH-R12000-T | ITH-R16000-T | ITH-R8000-MT | ITH-R12000-MT | ITH-R16000-MT | |
Dimension ( W x D x H )mm | Internal | 2000 x 2000 x 2000 | 3000 x 2000 x 2000 | 4000 x 2000 x 2000 | 2000 x 2000 x 2000 | 3000 x 2000 x 2000 | 4000 x 2000 x 2000 |
External | 2950 x 2200 x 2450 | 3950 x 2200 x 2450 | 4950 x 2200 x 2450 | 2950 x 2200 x 2450 | 3950 x 2200 x 2450 | 4950 x 2200 x 2450 | |
Capacity | 8000Liter | 12000Liter | 16000Liter | 8000Liter | 12000Liter | 16000Liter | |
Temperature | Fluctuation | ±1.0℃ ( -20℃ to +80℃ ) | ±1.0℃ ( -40℃ to +80℃ ) | ||||
Uniformity | ±2.0℃ ( -20℃ to +80℃ ) | ±2.0℃ ( -40℃ to +80℃ ) | |||||
Humidity | Fluctuation | ±2.0%RH | |||||
Uniformity | ±3.0%RH | ||||||
Time | Heat-Up Rate | +20℃ ~ +80℃ ( Within 60Min ) | |||||
Pull-Down Rate | +20℃ ~ -20℃ ( Within 40Min ) | +20℃ ~ -40℃ ( Within 60Min ) | |||||
Material | Internal | 18-8 Cr-Ni Stainless Steel Plate( 2B ) 0.5T | |||||
External | Colored sheet steel 0.5T | ||||||
Insulation | Polyurethane Foam 100T | ||||||
Refrigeration | Refrigerator | Semi-Hermatically sealed Compressor ( 반밀폐형 냉동기 ) | |||||
System | Single Stage Refrigeration System ( 단단냉동방식 ) | Mechanical Cascade Refrigeration System ( 이원냉동방식 ) | |||||
Capacity | 5HP | 7.5HP | 10HP | 5HP x 2Unit | 7.5HP x 2Unit | 10HP x 2Unit | |
Cooler | Plate Fin Cooler ( Air Cooled Type ) - 실외기 | ||||||
Dry Heater | Material | Nicrome Strip Wire Heater | |||||
Capacity | 12KW | 18KW | 24KW | 12KW | 18KW | 24KW | |
Wet Heater | Material | SUS316L Sheathed Heater | |||||
Capacity | 8KW | 12KW | 16KW | 8KW | 12KW | 16KW | |
Air Circulation | Motor | 1/2HP x 4 | 1HP x 4 | 1HP x 4 | 1/2HP x 4 | 1HP x 4 | 1HP x 4 |
Fan | 5" x 10" ( AL Sirocco ) | ||||||
Sensor | Temperature | PT 100Ω | |||||
Humidity | Electronic Sensor | ||||||
View Window | SAFETY GLASS , 열선내장(이슬 맺힘 방지) 400 x 500 x 41T | ||||||
Accessories | Cable Port ( 내경 : Φ50, 1EA ) - 협의가능, Lamp ( 50W ), Tower Lamp ( LED 3단 ) | ||||||
Power Supply | AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz | ||||||
Max Power | 25.9KW | 39.2KW | 51.1KW | 29.6KW | 44.7KW | 59.1KW | |
Load Current | AC220V 3Φ | 68.1A | 103A | 134.3A | 77.8A | 117.5A | 155.3A |
AC380V 3Φ | 39.4A | 59.6A | 77.7A | 45.1A | 68A | 89.9A | |
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
Temperature Room Chamber Specification / 항온실 ( 일반형 ) |
|||||||
|
IT-RT Series |
IT-RMT Series |
|||||
Temperature Range |
-20℃ ~ +80℃ |
-40℃ ~ +80℃ |
|||||
MODEL |
IT-R8000-T |
IT-R12000-T |
IT-R16000-T |
IT-R8000-MT |
IT-R12000-MT |
IT-R16000-MT |
|
Dimension ( W x D x H )mm |
Internal |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
External |
2950 x 2200 x 2450 |
3950 x 2200 x 2450 |
4950 x 2200 x 2450 |
2950 x 2200 x 2450 |
3950 x 2200 x 2450 |
4950 x 2200 x 2450 |
|
Capacity |
8000Liter |
12000Liter |
16000Liter |
8000Liter |
12000Liter |
16000Liter |
|
Temperature |
Fluctuation |
±1.0℃ ( -20℃ to +80℃ ) |
±1.0℃ ( -40℃ to +80℃ ) |
||||
Uniformity |
±2.0℃ ( -20℃ to +80℃ ) |
±2.0℃ ( -40℃ to +80℃ ) |
|||||
Time |
Heat-Up Rate |
+20℃ ~ +80℃ ( Within 60Min ) |
|||||
Pull-Down Rate |
+20℃ ~ -20℃ ( Within 40Min ) |
+20℃ ~ -40℃ ( Within 60Min ) |
|||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( 2B ) 0.5T |
|||||
External |
Colored sheet steel 0.5T |
||||||
Insulation |
Polyurethane Foam 100T |
||||||
Refrigeration |
Refrigerator |
Semi-Hermatically sealed Compressor ( 반밀폐형 냉동기 ) |
|||||
System |
Single Stage Refrigeration System ( 단단냉동방식 ) |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
|||||
Capacity |
5HP |
7.5HP |
10HP |
5HP x 2Unit |
7.5HP x 2Unit |
10HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) - 실외기 |
||||||
Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
12KW |
18KW |
24KW |
12KW |
18KW |
24KW |
|
Air Circulation |
Motor |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
Fan |
5" x 10" ( AL Sirocco ) |
||||||
Temp. Sensor |
PT 100Ω |
||||||
View Window |
SAFETY GLASS , 열선내장(이슬 맺힘 방지) 400 x 500 x 41T |
||||||
Accessories | Cable Port ( 내경 : Φ50, 1EA ) - 협의가능, Lamp ( 50W ), Tower Lamp ( LED 3단 ) | ||||||
Power Supply | AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz | ||||||
Max Power |
17.9KW |
27.2KW |
35.8KW |
21.6KW |
32.7KW |
43.2KW |
|
Load Current | AC220V 3Φ | 47.1A | 71.5A | 94.1A | 56.8A | 85.9A | 113.3A |
AC380V 3Φ | 27.2A | 41.4A | 54.5A | 32.9A | 49.7A | 65.7A | |
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
Low Humidity Temperature Room Chamber Specification / 저습항온항습실 |
|||||||
|
ITH-RTL Series |
ITH-RMTL Series |
|||||
Temperature Range |
-20℃ ~ +80℃ |
-40℃ ~ +80℃ |
|||||
Humidity Range |
5%RH ~ 98%RH |
5%RH ~ 98%RH |
|||||
MODEL |
ITH-R8000-TL |
ITH-R12000-TL |
ITH-R16000-TL |
ITH-R8000-MTL |
ITH-R12000-MTL |
ITH-R16000-MTL |
|
Dimension ( W x D x H )mm |
Internal |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
External |
2950 x 2200 x 2450 |
3950 x 2200 x 2450 |
4950 x 2200 x 2450 |
2950 x 2200 x 2450 |
3950 x 2200 x 2450 |
4950 x 2200 x 2450 |
|
Capacity |
8000Liter |
12000Liter |
16000Liter |
8000Liter |
12000Liter |
16000Liter |
|
Temperature |
Fluctuation |
±1.0℃ ( -20℃ to +80℃ ) |
±1.0℃ ( -40℃ to +80℃ ) |
||||
Uniformity |
±2.0℃ ( -20℃ to +80℃ ) |
±2.0℃ ( -40℃ to +80℃ ) |
|||||
Humidity |
Fluctuation |
±2.0%RH |
|||||
Uniformity |
±3.0%RH |
||||||
Time |
Heat-Up Rate |
'+20℃ ~ +80℃ ( Within 60Min ) |
|||||
Pull-Down Rate |
+20℃ ~ -20℃ ( Within 40Min ) |
+20℃ ~ -40℃ ( Within 60Min ) |
|||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( 2B ) 0.5T |
|||||
External |
Colored sheet steel 0.5T |
||||||
Insulation |
Polyurethane Foam 100T |
||||||
Refrigeration |
Refrigerator |
Semi-Hermatically sealed Compressor ( 반밀폐형 냉동기 ) |
|||||
System |
Single Stage Refrigeration System ( 단단냉동방식 ) |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
|||||
Capacity |
5HP |
7.5HP |
10HP |
5HP x 2Unit |
7.5HP x 2Unit |
10HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
12KW |
18KW |
24KW |
12KW |
18KW |
24KW |
|
Wet Heater |
Material |
SUS316L Sheathed Heater |
|||||
Capacity |
8KW |
12KW |
16KW |
8KW |
12KW |
16KW |
|
Air Circulation |
Motor |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
Fan |
5" x 10" ( AL Sirocco ) |
||||||
Sensor |
Temperature |
PT 100Ω |
|||||
Humidity |
Electronic Sensor |
||||||
View Window |
SAFETY GLASS , 열선내장(이슬 맺힘 방지) 400 x 500 x 41T |
||||||
Accessories | Cable Port ( 내경 : Φ50, 1EA ) - 협의가능, Lamp ( 50W ), Tower Lamp ( LED 3단 ) | ||||||
Power Supply | AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz | ||||||
Max Power | 25.9KW | 39.2KW | 51.1KW | 29.6KW | 44.7KW | 59.1KW | |
Load Current | AC220V 3Φ | 68.1A | 103A | 134.3A | 77.8A | 117.5A | 155.3A |
AC380V 3Φ | 39.4A | 59.6A | 77.7A | 45.1A | 68A | 89.9A | |
※ Dehumidifier specifications are determined after consultation.
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
High Temperature & Humidity Room Chamber Specification / 고온항온항습실 |
|||||||
|
ITH-RHT Series |
ITH-RMHT Series |
|||||
Temperature Range |
-20℃ ~ +150℃ |
-40℃ ~ +150℃ |
|||||
Humididity Range |
20%RH ~ 98%RH |
20%RH ~ 98%RH |
|||||
MODEL |
ITH-R8000-HT |
ITH-R12000-HT |
ITH-R16000-HT |
ITH-R8000-MHT |
ITH-R12000-MHT |
ITH-R16000-MHT |
|
Dimension ( W x D x H )mm |
Internal |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
External |
3050 x 2300 x 2505 |
4050 x 2300 x 2505 |
5050 x 2300 x 2505 |
3050 x 2300 x 2505 |
4050 x 2300 x 2505 |
5050 x 2300 x 2505 |
|
Capacity |
8000Liter |
12000Liter |
16000Liter |
8000Liter |
12000Liter |
16000Liter |
|
Temperature |
Fluctuation |
±1.0℃ ( -20℃ to +100℃ ) |
±1.0℃ ( -40℃ to +150℃ ) |
||||
Uniformity |
±2.0℃ ( -20℃ to +100℃ ) |
±2.0℃ ( -40℃ to +150℃ ) |
|||||
Humidity |
Fluctuation |
±2.0%RH |
|||||
Uniformity |
±3.0%RH |
||||||
Time |
Heat-Up Rate |
+20℃ ~ +100℃ ( Within 80Min ) |
+20℃ ~ +150℃ ( Within 130Min ) |
||||
Pull-Down Rate |
+20℃ ~ -20℃ ( Within 40Min ) |
+20℃ ~ -40℃ ( Within 60Min ) |
|||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( Polish ) 1.5T ( 바닥보강 ) |
|||||
External |
CR Steel Plate 1.6T ( 아이보리 햄마톤 도장 ) |
||||||
Insulation |
Polyurethane Foam 150T |
||||||
Refrigeration |
Refrigerator |
Semi-Hermatically sealed Compressor ( 반밀폐형 냉동기 ) |
|||||
System |
Single Stage Refrigeration System ( 단단냉동방식 ) |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
|||||
Capacity |
5HP |
7.5HP |
10HP |
5HP x 2Unit |
7.5HP x 2Unit |
10HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) - 실외기 |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
12KW |
18KW |
24KW |
12KW |
18KW |
24KW |
|
Wet Heater |
Material |
SUS316L Sheathed Heater |
|||||
Capacity |
8KW |
12KW |
16KW |
8KW |
12KW |
16KW |
|
Air Circulation |
Motor |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
Fan |
5" x 10" ( AL Sirocco ) |
||||||
Sensor |
Temperature |
PT 100Ω |
|||||
Humidity |
Electronic Sensor |
||||||
View Window |
SAFETY GLASS , 열선내장(이슬 맺힘 방지) 400 x 500 x 41T |
||||||
Accessories | Cable Port ( 내경 : Φ50, 1EA ) - 협의가능, Lamp ( 50W ), Tower Lamp ( LED 3단 ) | ||||||
Power Supply | AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz | ||||||
Max Power | 25.9KW | 39.2KW | 51.1KW | 29.6KW | 44.7KW | 59.1KW | |
Load Current | AC220V 3Φ | 68.1A | 103A | 134.3A | 77.8A | 117.5A | 155.3A |
AC380V 3Φ | 39.4A | 59.6A | 77.7A | 45.1A | 68A | 89.9A | |
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
High Temperature Chamber Specification / 고온항온실 |
|||||||
|
IT-RHT Series |
IT-RMHT Series |
|||||
Temperature Range |
-20℃ ~ +150℃ |
-40℃ ~ +150℃ |
|||||
MODEL |
ITH-R8000-HT |
ITH-R12000-HT |
ITH-R16000-HT |
ITH-R8000-MHT |
ITH-R12000-MHT |
ITH-R16000-MHT |
|
Dimension ( W x D x H )mm |
Internal |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
2000 x 2000 x 2000 |
3000 x 2000 x 2000 |
4000 x 2000 x 2000 |
External |
3050 x 2300 x 2505 |
4050 x 2300 x 2505 |
5050 x 2300 x 2505 |
3050 x 2300 x 2505 |
4050 x 2300 x 2505 |
5050 x 2300 x 2505 |
|
Capacity |
8000Liter |
12000Liter |
16000Liter |
8000Liter |
12000Liter |
16000Liter |
|
Temperature |
Fluctuation |
±1.0℃ ( -20℃ to +100℃ ) |
±1.0℃ ( -40℃ to +150℃ ) |
||||
Uniformity |
±2.0℃ ( -20℃ to +100℃ ) |
±2.0℃ ( -40℃ to +150℃ ) |
|||||
Time |
Heat-Up Rate |
+20℃ ~ +100℃ ( Within 80Min ) |
+20℃ ~ +150℃ ( Within 130Min ) |
||||
Pull-Down Rate |
+20℃ ~ -20℃ ( Within 40Min ) |
+20℃ ~ -40℃ ( Within 60Min ) |
|||||
Material |
Internal |
18-8 Cr-Ni Stainless Steel Plate( Polish ) 1.5T ( 바닥보강 ) |
|||||
External |
CR Steel Plate 1.6T ( 아이보리 햄마톤 도장 ) |
||||||
Insulation |
Polyurethane Foam 150T |
||||||
Refrigeration |
Refrigerator |
Semi-Hermatically sealed Compressor ( 반밀폐형 냉동기 ) |
|||||
System |
Single Stage Refrigeration System ( 단단냉동방식 ) |
Mechanical Cascade Refrigeration System ( 이원냉동방식 ) |
|||||
Capacity |
5HP |
7.5HP |
10HP |
5HP x 2Unit |
7.5HP x 2Unit |
10HP x 2Unit |
|
Cooler |
Plate Fin Cooler ( Air Cooled Type ) - 실외기 |
||||||
Dry Heater |
Material |
Nicrome Strip Wire Heater |
|||||
Capacity |
12KW |
18KW |
24KW |
12KW |
18KW |
24KW |
|
Air Circulation |
Motor |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
1/2HP x 4 |
1HP x 4 |
1HP x 4 |
Fan |
5" x 10" ( AL Sirocco ) |
||||||
Sensor |
Temperature |
PT 100Ω |
|||||
View Window |
SAFETY GLASS , 열선내장(이슬 맺힘 방지) 400 x 500 x 41T |
||||||
Accessories |
Cable Port ( 내경 : Φ50, 1EA ) - 협의가능, Lamp ( 50W ), Tower Lamp ( LED 3단 ) |
||||||
Power Supply |
AC220V 3Φ 4W 50/60Hz, AC380V 3Φ 4W 50/60Hz |
||||||
Max Power |
17.7KW |
27.2KW |
35.1KW |
21.6KW |
32.7KW |
43.1KW |
|
Load Current |
AC220V 3Φ |
46.5A |
71.5A |
92.2A |
56.8A |
85.9A |
113.2A |
AC380V 3Φ |
26.9A |
41.4A |
53.4A |
32.9A |
49.7A |
65.6A |
|
※ Specifications other than the special specifications can be made after consultation.
※ Work Environment : +10℃ ~ +30℃, 85%RH Under
